QC11Y/K Series Hydraulic Guillotine (CNC) Shearing Machine

Cutting machine

QC11Y/K Series Hydraulic Guillotine (CNC) Shearing Machine

Product code : QC11/K
Origin : Trung Quốc
Price : Contact

Features

The rolling guide structure is supported by three points;
The shear Angle of the tool holder can be adjusted in the range;
Shear travel can be adjusted arbitrarily;
Manual lifting of the retaining function;
The inside of the wallboard is equipped with a lubricating oil pump;
The standard E21S numerical control system controls the cut count and the post-block;
A variety of numerical control systems such as DAC360 can be selected.

Product Description

OPTIONAL CNC

	ESTUN E21S Backgauge control Control ordinary motors or inverters Intelligent positioning Dual programmable digital output Workpiece count 40 program storage, each program has 25 steps Unilateral positioning Yield function One-key backup and restore of parameters Metric system
	ESTUN E200PS CAN bus control X axis servo Shear control Dual programmable digital output 40 program storage, each program has 25 steps Unilateral positioning Built-in cutting time, retreat delay One-key backup and restore of parameters Full-function online diagnosis, real-time alarm prompt Reserve a safe, supporting material interface Color LCD HD display Metric/English Chinese-English
	DELEM DAC310 High-definition LCD display, 128x64 pixels Backgauge control Knife edge gap control Cutting stroke control The actual position of the back gauge is displayed synchronously with the programmed value Cut count 100 steps Panel mount Servo control / frequency conversion speed control/two-speed AC motor control
	DELEM DAC360 High brightness LCD display Backgauge control Yield function Shear angle control Shear gap control Cutting stroke control Each axis can be moved manually Pressure control

Hydraulic Hold-down Pads

Unique structure of the pressure cylinder, built-in spring, the lower end with a special material gasket. When the plate is sheared, the gasket can be in close contact with the material plate, which can effectively prevent the pllate from shaking during the shearing process.
