CNC Vertical Slotting Machine

Feature

• This series of CNC V groover machine is an upgraded product of traditional equipment. Compared with traditional equip-ment, it is characterized by heavy load, high speed and high efficiency.
• This equipment adopts frame structure design, high-strength bolt connection, good overall rigidity and small deformation. The crossbeam of this equipment is fixed and the work can be replaced by the feed mechanism. Ensure that the flatness of the work surface is within ± 0.03mm.
• This equipment uses a carbon tool steel workbench, hardness after quenching reaches HRC55 or more. Therefore, the table wear is very small and the surface can be changed, thereby prolonging the service life of the equipment.
• This equipment has a 5.6kW high-power servo motor. The cutter body is equipped with 4 cutting tools at the same time. The maximum cutting depth is 1mm, which is 5 times that of traditional equipment and the speed of return is also 5 times faster.
